The suspended dry powder fire extinguishing device consists of ultra-fine dry powder fire extinguishing agent, driving medium, fire extinguishing agent storage tank, initiator component (thermal initiator component, electric initiator component optional), and other components. It is a fire extinguishing device installed in high-temperature and flammable parts such as ships, vehicle engine compartments, battery compartments, and retarders, and can be used to extinguish Class A, B, C, and E fires.
Technical Specifications
| No. | Item | Parameter / Performance |
|---|---|---|
| 1 | Electric Starting Voltage Range | 5‑24VDC |
| 2 | Starting Current | ≥1A |
| 3 | Operating Mode | Manual Mode / Automatic Mode |
| 4 | Design Service Life | 4 years (Maintenance‑free) |
| 5 | Operating Temperature | -40℃ ~ 90℃ |
| 6 | Operating Humidity | ＜95% |
| 7 | Mounting Method | Suspended Type |
| 8 | Dry Powder Type | ABC Ultra‑fine Dry Powder |
| 9 | Discharge Time | ≤5s |
| 10 | Residual Discharge Rate | ≤5% |
| 11 | Filling Weight Deviation | 0~5% |
| 12 | Start Response Time | 2s |
| 13 | Fire Extinguishing Performance | Fire suppression within 30s |
The suspended dry powder fire extinguishing device consists of ultra-fine dry powder fire extinguishing agent, driving medium, fire extinguishing agent storage tank, initiator component (thermal initiator component, electric initiator component optional), and other components. It is a fire extinguishing device installed in high-temperature and flammable parts such as ships, vehicle engine compartments, battery compartments, and retarders, and can be used to extinguish Class A, B, C, and E fires.
Technical Specifications
| No. | Item | Parameter / Performance |
|---|---|---|
| 1 | Electric Starting Voltage Range | 5‑24VDC |
| 2 | Starting Current | ≥1A |
| 3 | Operating Mode | Manual Mode / Automatic Mode |
| 4 | Design Service Life | 4 years (Maintenance‑free) |
| 5 | Operating Temperature | -40℃ ~ 90℃ |
| 6 | Operating Humidity | ＜95% |
| 7 | Mounting Method | Suspended Type |
| 8 | Dry Powder Type | ABC Ultra‑fine Dry Powder |
| 9 | Discharge Time | ≤5s |
| 10 | Residual Discharge Rate | ≤5% |
| 11 | Filling Weight Deviation | 0~5% |
| 12 | Start Response Time | 2s |
| 13 | Fire Extinguishing Performance | Fire suppression within 30s |
